DISCLAIMER: The detailed information for each source shown in this section has been generated with an automatic reduction process, line fitting, and line identification tool. There is no guarantee about the quality of this information, and for research purposes you should perform line fitting and identification yourself. The data was taken in frequency switching mode, so some atmospheric lines could appear in the data. The detailed report is provided because it could be useful to get an idea of the main lines detected in each position.

CAUTION: Do not trust in wide lines (line width > 2 km/s) that might be due to baseline problems and/or atmospheric lines. Do not trust in “exotic” line identifications that are more likely due to a spurious match with the line catalogue.

TMC1-CAL-120_0

Backend 3mm (85.0-110.5 GHz)

Found 49 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
0.281 (0.017) 0.47 (0.09) 0.142 (0.025) 5.784 (0.009) 85338.96 85338.90 19.0 c-C3H2 21,2→10,1 tmc1-cal-120_0:3mm_red_0.png tmc1-cal-120_0:3mm_ori_0.png
0.055 (0.017) 0.5 (0.5) 0.03 (0.03) 5.11 (0.06) 85927.14 85926.88 3.8 NH2D 11,1→10,1 F=1-2 tmc1-cal-120_0:3mm_red_1.png tmc1-cal-120_0:3mm_ori_1.png
0.206 (0.019) 0.56 (0.17) 0.12 (0.04) 5.740 (0.018) 86754.36 86754.29 11.9 H13CO+ 1→0 tmc1-cal-120_0:3mm_red_2.png tmc1-cal-120_0:3mm_ori_2.png
0.07 (0.03) 0.2 (0.4) 0.018 (0.023) 3.05 (0.04) 88442.58 88441.71 4.1 He(52)</sup>\beta</sup> tmc1-cal-120_0:3mm_red_3.png tmc1-cal-120_0:3mm_ori_3.png
0.090 (0.018) 0.4 (0.3) 0.039 (0.024) 6.21 (0.03) 88630.36 88630.42 6.3 HCN 1→0 F=1→1 tmc1-cal-120_0:3mm_red_4.png tmc1-cal-120_0:3mm_ori_4.png
0.229 (0.021) 0.43 (0.11) 0.104 (0.024) 5.554 (0.011) 88630.55 88630.42 16.2 HCN 1→0 F=1→1 tmc1-cal-120_0:3mm_red_5.png tmc1-cal-120_0:3mm_ori_5.png
0.104 (0.016) 0.39 (0.18) 0.043 (0.020) 6.250 (0.020) 88631.77 88631.85 7.9 HCN 1→0 F=2→1 tmc1-cal-120_0:3mm_red_6.png tmc1-cal-120_0:3mm_ori_6.png
0.424 (0.017) 0.37 (0.05) 0.165 (0.019) 5.510 (0.005) 88631.99 88631.85 31.9 HCN 1→0 F=2→1 tmc1-cal-120_0:3mm_red_7.png tmc1-cal-120_0:3mm_ori_7.png
0.045 (0.017) 0.3 (0.4) 0.013 (0.017) 8.76 (0.05) 88633.13 88633.94 3.4 HCN 1→0 F=0→1 tmc1-cal-120_0:3mm_red_8.png tmc1-cal-120_0:3mm_ori_8.png
0.188 (0.014) 0.55 (0.13) 0.110 (0.024) 5.682 (0.014) 88634.03 88633.94 14.2 HCN 1→0 F=0→1 tmc1-cal-120_0:3mm_red_9.png tmc1-cal-120_0:3mm_ori_9.png
0.250 (0.015) 0.47 (0.09) 0.124 (0.022) 6.289 (0.009) 89188.44 89188.53 16.6 HCO+ 1→0 tmc1-cal-120_0:3mm_red_10.png tmc1-cal-120_0:3mm_ori_10.png
0.609 (0.016) 0.48 (0.04) 0.309 (0.022) 5.487 (0.004) 89188.68 89188.53 40.9 HCO+ 1→0 tmc1-cal-120_0:3mm_red_11.png tmc1-cal-120_0:3mm_ori_11.png
0.160 (0.017) 0.56 (0.20) 0.10 (0.04) 6.141 (0.021) 90663.52 90663.56 9.5 HNC 1→0 tmc1-cal-120_0:3mm_red_12.png tmc1-cal-120_0:3mm_ori_12.png
0.737 (0.023) 0.35 (0.04) 0.275 (0.025) 5.449 (0.004) 90663.73 90663.56 43.2 HNC 1→0 tmc1-cal-120_0:3mm_red_13.png tmc1-cal-120_0:3mm_ori_13.png
0.06 (0.03) 0.4 (0.4) 0.025 (0.024) 5.91 (0.06) 90979.03 90979.00 4.2 HC3N 10→9 (3 components around) tmc1-cal-120_0:3mm_red_14.png tmc1-cal-120_0:3mm_ori_14.png
0.047 (0.007) 0.57 (0.25) 0.028 (0.012) 5.45 (0.03) 93172.05 93171.88 6.9 N2H+ 1→0 F=1→1 tmc1-cal-120_0:3mm_red_15.png tmc1-cal-120_0:3mm_ori_15.png
0.044 (0.009) 0.34 (0.23) 0.016 (0.011) 6.48 (0.03) 93173.55 93173.70 6.0 N2H+ 1→0 F=1→2 tmc1-cal-120_0:3mm_red_16.png tmc1-cal-120_0:3mm_ori_16.png
0.060 (0.011) 0.30 (0.16) 0.019 (0.009) 5.446 (0.017) 93173.87 93173.70 8.3 N2H+ 1→0 F=1→2 tmc1-cal-120_0:3mm_red_17.png tmc1-cal-120_0:3mm_ori_17.png
0.040 (0.009) 0.4 (0.3) 0.018 (0.012) 5.31 (0.04) 93176.34 93176.13 5.5 N2H+ 1→0 F=1→0 tmc1-cal-120_0:3mm_red_18.png tmc1-cal-120_0:3mm_ori_18.png
0.042 (0.009) 1.1 (0.6) 0.049 (0.024) 5.78 (0.07) 93856.88 93856.8 4.9 Unidentified 93.857 GHz tmc1-cal-120_0:3mm_red_19.png tmc1-cal-120_0:3mm_ori_19.png
0.026 (0.008) 0.5 (0.5) 0.015 (0.014) 5.87 (0.07) 93870.14 93870.10 3.6 C2S N=7→6 J=8→7 tmc1-cal-120_0:3mm_red_20.png tmc1-cal-120_0:3mm_ori_20.png
0.053 (0.019) 2.3 (1.6) 0.13 (0.08) 5.78 (0.14) 93958.69 93958.6 2.5 Unidentified 93.959 GHz tmc1-cal-120_0:3mm_red_21.png tmc1-cal-120_0:3mm_ori_21.png
0.069 (0.022) 1.3 (0.9) 0.10 (0.06) 5.78 (0.09) 93959.12 93959.1 3.3 Unidentified 93.959 GHz tmc1-cal-120_0:3mm_red_22.png tmc1-cal-120_0:3mm_ori_22.png
0.413 (0.015) 0.08 (0.03) 0.037 (0.012) 6.00 (0.08) 94083.69 94083.69 28.5 ONCN 9-8 in atmosphere ? tmc1-cal-120_0:3mm_red_23.png tmc1-cal-120_0:3mm_ori_23.png
1.047 (0.015) 0.081 (0.010) 0.091 (0.011) 5.78 (0.08) 94083.99 94083.9 72.2 Unidentified 94.084 GHz tmc1-cal-120_0:3mm_red_24.png tmc1-cal-120_0:3mm_ori_24.png
0.031 (0.009) 2.9 (1.6) 0.10 (0.05) 9.36 (0.14) 95809.34 95810.41 4.1 34SO2 2(2,0)-3(1,3) tmc1-cal-120_0:3mm_red_25.png tmc1-cal-120_0:3mm_ori_25.png
0.114 (0.008) 3.6 (0.4) 0.43 (0.04) 5.10 (0.04) 96241.10 96240.81 13.4 CNCHO 22(3,19)-23(2,22) tmc1-cal-120_0:3mm_red_26.png tmc1-cal-120_0:3mm_ori_26.png
0.147 (0.008) 1.17 (0.16) 0.183 (0.022) 4.481 (0.016) 96241.30 96240.81 17.3 CNCHO 22(3,19)-23(2,22) tmc1-cal-120_0:3mm_red_27.png tmc1-cal-120_0:3mm_ori_27.png
0.064 (0.006) 0.53 (0.18) 0.036 (0.012) 5.867 (0.019) 96412.99 96412.95 8.9 C34S 2→1 tmc1-cal-120_0:3mm_red_28.png tmc1-cal-120_0:3mm_ori_28.png
0.083 (0.007) 0.48 (0.15) 0.043 (0.012) 5.785 (0.016) 96739.43 96739.36 10.4 CH3OH 2(-1,2)→1(-1,1) tmc1-cal-120_0:3mm_red_29.png tmc1-cal-120_0:3mm_ori_29.png
0.119 (0.007) 0.58 (0.11) 0.073 (0.013) 5.739 (0.012) 96741.46 96741.37 14.6 CH3OH 2(0,2)→1(0,1) ++ tmc1-cal-120_0:3mm_red_30.png tmc1-cal-120_0:3mm_ori_30.png
1.986 (0.015) 0.235 (0.005) 0.497 (0.010) 5.7852 (0.0006) 96911.03 96911.0 86.4 Unidentified 96.911 GHz tmc1-cal-120_0:3mm_red_31.png tmc1-cal-120_0:3mm_ori_31.png
2.527 (0.021) 0.213 (0.004) 0.574 (0.009) 5.7853 (0.0003) 96926.06 96926.0 95.9 Unidentified 96.926 GHz tmc1-cal-120_0:3mm_red_32.png tmc1-cal-120_0:3mm_ori_32.png
0.209 (0.014) 0.54 (0.11) 0.121 (0.023) 6.117 (0.012) 97980.91 97980.95 15.3 CS 2→1 tmc1-cal-120_0:3mm_red_33.png tmc1-cal-120_0:3mm_ori_33.png
0.690 (0.019) 0.321 (0.025) 0.236 (0.018) 5.589 (0.003) 97981.09 97980.95 50.7 CS 2→1 tmc1-cal-120_0:3mm_red_34.png tmc1-cal-120_0:3mm_ori_34.png
0.035 (0.012) 0.4 (0.5) 0.017 (0.016) 4.54 (0.06) 99275.20 99274.72 4.0 C(50)</sup>\beta</sup> tmc1-cal-120_0:3mm_red_35.png tmc1-cal-120_0:3mm_ori_35.png
0.251 (0.011) 0.51 (0.07) 0.136 (0.016) 5.978 (0.007) 99299.90 99299.89 26.3 SO 3(2)→2(1) tmc1-cal-120_0:3mm_red_36.png tmc1-cal-120_0:3mm_ori_36.png
0.143 (0.014) 0.28 (0.08) 0.042 (0.012) 5.590 (0.009) 99300.03 99299.89 15.3 SO 3(2)→2(1) tmc1-cal-120_0:3mm_red_37.png tmc1-cal-120_0:3mm_ori_37.png
0.040 (0.010) 0.7 (0.6) 0.028 (0.021) 5.87 (0.06) 101477.85 101477.81 4.1 H2CS 3(1,3)→2(1,2) tmc1-cal-120_0:3mm_red_38.png tmc1-cal-120_0:3mm_ori_38.png
0.130 (0.012) 0.09 (0.07) 0.012 (0.009) 4.60 (0.08) 102064.74 102064.27 10.4 NH2CHO 5(1,5)→4(1,4) tmc1-cal-120_0:3mm_red_39.png tmc1-cal-120_0:3mm_ori_39.png
0.038 (0.013) 0.4 (0.5) 0.017 (0.017) 9.19 (0.05) 102539.05 102540.14 3.9 CH3CCH 6(2)→5(2) tmc1-cal-120_0:3mm_red_40.png tmc1-cal-120_0:3mm_ori_40.png
0 (60) 0 (4) 0 (5) 5.81 (0.03) 109561.06 109561.0 14.7 Unidentified 109.560 GHz tmc1-cal-120_0:3mm_red_41.png tmc1-cal-120_0:3mm_ori_41.png
0.108 (0.025) 1.7 (0.8) 0.19 (0.09) 5.81 (0.09) 109561.99 109561.9 4.3 Unidentified 109.560 GHz tmc1-cal-120_0:3mm_red_42.png tmc1-cal-120_0:3mm_ori_42.png
0.10 (0.03) 0.7 (0.5) 0.08 (0.06) 5.81 (0.06) 109563.86 109563.8 4.3 Unidentified 109.563 GHz tmc1-cal-120_0:3mm_red_43.png tmc1-cal-120_0:3mm_ori_43.png
0.12 (0.03) 0.5 (0.4) 0.06 (0.05) 6.54 (0.05) 109781.98 109782.18 2.7 C18O 1→0 tmc1-cal-120_0:3mm_red_44.png tmc1-cal-120_0:3mm_ori_44.png
1.00 (0.04) 0.31 (0.03) 0.33 (0.04) 6.090 (0.004) 109782.14 109782.18 22.7 C18O 1→0 tmc1-cal-120_0:3mm_red_45.png tmc1-cal-120_0:3mm_ori_45.png
1.74 (0.03) 0.578 (0.025) 1.07 (0.05) 5.678 (0.003) 109782.29 109782.18 39.5 C18O 1→0 tmc1-cal-120_0:3mm_red_46.png tmc1-cal-120_0:3mm_ori_46.png
2.60 (0.03) 1.75 (0.04) 4.85 (0.09) 6.241 (0.004) 110201.26 110201.35 20.4 13CO 1→0 tmc1-cal-120_0:3mm_red_47.png tmc1-cal-120_0:3mm_ori_47.png
3.54 (0.03) 1.281 (0.023) 4.82 (0.08) 5.4573 (0.0023) 110201.55 110201.35 27.8 13CO 1→0 tmc1-cal-120_0:3mm_red_48.png tmc1-cal-120_0:3mm_ori_48.png

Backend 2mm (134.6 GHz)

Backend 2mm (137.9 GHz)

Found 4 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
0.05 (0.03) 0.14 (0.25) 0.007 (0.013) 5.44 (0.04) 137554.01 137553.75 4.2 CaNC N=17-16, J=33/2-31/2 (3x) tmc1-cal-120_0:2mm_137.9_red_0.png tmc1-cal-120_0:2mm_137.9_ori_0.png
0.058 (0.016) 0.5 (0.4) 0.030 (0.023) 6.08 (0.04) 138178.62 138178.66 5.0 SO 43→32 tmc1-cal-120_0:2mm_137.9_red_1.png tmc1-cal-120_0:2mm_137.9_ori_1.png
0.088 (0.020) 0.14 (0.13) 0.013 (0.012) 5.443 (0.015) 138253.99 138253.7 9.1 Unidentified 138.254 GHz tmc1-cal-120_0:2mm_137.9_red_2.png tmc1-cal-120_0:2mm_137.9_ori_2.png
0.074 (0.023) 0.12 (0.15) 0.010 (0.011) 5.445 (0.021) 138753.99 138753.7 7.3 Unidentified 138.754 GHz tmc1-cal-120_0:2mm_137.9_red_3.png tmc1-cal-120_0:2mm_137.9_ori_3.png

Backend 2mm (144.1 GHz)

Backend 2mm (147.3 GHz)

Found 1 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
0.23 (0.05) 0.6 (0.5) 0.15 (0.10) 5.73 (0.04) 146969.16 146969.03 5.5 CS 3→2 tmc1-cal-120_0:2mm_147.3_red_0.png tmc1-cal-120_0:2mm_147.3_ori_0.png

Backend 2mm (168.2 GHz)

Found 2 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
0.09 (0.04) 1.9 (2.0) 0.18 (0.18) 7.98 (0.12) 167572.42 167573.53 2.2 c-13CCCH 13(7,6)-13(7,7) tmc1-cal-120_0:2mm_168.2_red_0.png tmc1-cal-120_0:2mm_168.2_ori_0.png
0.356 (0.024) 0.05 (0.05) 0.019 (0.018) 5.83 (0.05) 168577.95 168577.86 14.6 CH3OH 4(1,3)→3(2,1) tmc1-cal-120_0:2mm_168.2_red_1.png tmc1-cal-120_0:2mm_168.2_ori_1.png

Backend 2mm (171.5 GHz)

Found 5 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
1.70 (0.04) 0.048 (0.015) 0.09 (0.03) 5.07 (0.05) 172106.10 172105.56 47.1 HS2 11(2,9)-10(2,8), J=21/2-19/2, F=11-10 tmc1-cal-120_0:2mm_171.5_red_0.png tmc1-cal-120_0:2mm_171.5_ori_0.png
0.12 (0.04) 0.3 (0.5) 0.03 (0.07) 5.07 (0.04) 172203.08 172202.5 3.2 Unidentified 172.203 GHz tmc1-cal-120_0:2mm_171.5_red_1.png tmc1-cal-120_0:2mm_171.5_ori_1.png
0.15 (0.07) 0.1 (0.3) 0.02 (0.05) 5.072 (0.021) 172226.77 172226.2 3.9 Unidentified 172.227 GHz tmc1-cal-120_0:2mm_171.5_red_2.png tmc1-cal-120_0:2mm_171.5_ori_2.png
2.26 (0.04) 0.049 (0.012) 0.12 (0.03) 5.30 (0.05) 172232.95 172232.55 62.2 S2O 17(3,14)-17(2,15) tmc1-cal-120_0:2mm_171.5_red_3.png tmc1-cal-120_0:2mm_171.5_ori_3.png
0.08 (0.05) 0.3 (0.9) 0.03 (0.08) 3.65 (0.07) 172233.90 172232.55 2.2 S2O 17(3,14)-17(2,15) tmc1-cal-120_0:2mm_171.5_red_4.png tmc1-cal-120_0:2mm_171.5_ori_4.png

Backend 1mm (212.7-220.9 GHz)

Found 10 lines:

Tmb (K) Width (km/s) I (K km/s) Vlsr (km/s) Obs. freq (MHz) Rest freq (MHz) S/N ratio Transition Reduced spectrum Original spectrum
2.79 (0.23) 0.11 (0.05) 0.31 (0.13) 6.0086 (0.0020) 213141.09 213141.1 30.1 Unidentified 213.141 GHz tmc1-cal-120_0:1mm_red_0.png tmc1-cal-120_0:1mm_ori_0.png
0.6 (0.3) 0.10 (0.18) 0.06 (0.12) 6.009 (0.009) 214040.89 214040.9 6.5 Unidentified 214.041 GHz tmc1-cal-120_0:1mm_red_1.png tmc1-cal-120_0:1mm_ori_1.png
1.52 (0.15) 0.12 (0.08) 0.19 (0.12) 6.009 (0.004) 214439.20 214439.2 14.6 Unidentified 214.439 GHz tmc1-cal-120_0:1mm_red_2.png tmc1-cal-120_0:1mm_ori_2.png
2.2 (0.3) 0.10 (0.05) 0.22 (0.11) 6.0086 (0.0020) 214459.21 214459.2 14.0 Unidentified 214.459 GHz tmc1-cal-120_0:1mm_red_3.png tmc1-cal-120_0:1mm_ori_3.png
0.38 (0.14) 0.11 (0.20) 0.04 (0.08) 6.009 (0.009) 216153.13 216153.1 6.5 Unidentified 216.153 GHz tmc1-cal-120_0:1mm_red_4.png tmc1-cal-120_0:1mm_ori_4.png
0.22 (0.06) 0.2 (0.5) 0.06 (0.11) 6.008 (0.022) 217167.90 217167.9 4.0 Unidentified 217.168 GHz tmc1-cal-120_0:1mm_red_5.png tmc1-cal-120_0:1mm_ori_5.png
0.82 (0.10) 0.4 (0.3) 0.34 (0.24) 6.008 (0.014) 219560.35 219560.36 9.1 C18O 2→1 tmc1-cal-120_0:1mm_red_6.png tmc1-cal-120_0:1mm_ori_6.png
0.86 (0.13) 0.20 (0.19) 0.19 (0.17) 5.638 (0.009) 219560.63 219560.36 9.3 C18O 2→1 tmc1-cal-120_0:1mm_red_7.png tmc1-cal-120_0:1mm_ori_7.png
1.64 (0.09) 1.4 (0.3) 2.4 (0.5) 6.024 (0.012) 220398.66 220398.68 12.3 13CO 2→1 tmc1-cal-120_0:1mm_red_8.png tmc1-cal-120_0:1mm_ori_8.png
1.59 (0.09) 0.66 (0.18) 1.1 (0.3) 5.375 (0.009) 220399.14 220398.68 12.1 13CO 2→1 tmc1-cal-120_0:1mm_red_9.png tmc1-cal-120_0:1mm_ori_9.png
